Our GE locomotive parts are built to meet the rigorous demands of modern rail operations, performing reliably under extreme load, vibration, and temperature conditions. Every component—be it a traction motor part, turbocharger, fuel injector, blower assembly, or auxiliary unit—is precisely engineered and thoroughly tested to ensure superior durability and consistent performance.
Manufactured using high-strength alloys and advanced materials, these parts offer an optimal balance of toughness and efficiency. Once integrated, they deliver dependable operation over extended service intervals. To further enhance longevity and reduce downtime, all parts are treated with industry-grade protective coatings that resist corrosion, thermal stress, and mechanical wear. Backed by expert support and field-proven quality, our GE parts and services are trusted to keep your fleet running efficiently—mile after mile.
GE Locomotive Parts
| Sr. No. | Part Description | OEM Part No. |
|---|---|---|
| 1 | Bearing, Blower End Turbocharger Model 7S1412 | 126X1087-2 |
| 2 | Bearing, Blower End Turbocharger Model 7S1612 | 126X1233-1 |
| 3 | Bearing, Half, Lower | 117X1045-2 |
| 4 | Bearing, Half, Upper | 117X1070 |
| 5 | Bearing, Main, Groove less Low | 114X1150 |
| 6 | Bearing, Main, Grooved Upper | 114X1103-1 |
| 7 | Bellow 128 X | 1638 |
| 8 | Bellow Main (128 X 1648) 128 X | 1689 |
| 9 | Blower End Bearing 126 X | 1087-2 |
| 10 | Blower End Bearing | 126X1223-1 |
| 11 | Blower End Bearing | 84D721240P1 |
| 12 | Bolt, 3/8"-24, 12PT Head, 1-5/8 LG. GR8 | 126X1455 |
| 13 | Bolt, For Shroud, Hex Head, 3/8"-24, 12PT Head, 2-1/2" LG, GR8 | 126X1451 |
| 14 | Bolt, Hex Head, 1/2"-13, 1-1/4" Long, GR8 (Same As 2151285) | N22P29020 |
| 15 | Bolt, Hex Head, 1/2"-13, 1-3/4" Long, GR8 | 126X1642 |
| 16 | Bolt, Hex Head, 1/2"-13, 1-3/4" Long, GR8 | N22P29028 |
| 17 | Bolt, Hex Head, 1/4"-20, 5/8" Long, GR8 | 126X1486 |
| 18 | Bolt, Hex Head, 3/8"-16, 2" Long, Drilled Head, GR8 | 115X2473 |
| 19 | Bolt, Hex Head, 5/8"-11, 1-3/4" Long, GR.8 | 115X2368 |
| 20 | Bolt, Hex Head, 5/8"-13, 1-3/4" Long, Drilled Head, GR8 | N14P33028 |
| 21 | Bolt, Socket Head, 1/4"-20 X 3/4" Long GR8 | 126X1468 |
| 22 | Brush Box | 1X8670 |
| 23 | Carbon Bruch, With Pig Tail | 41A235676P4 |
| 24 | Carbon Brush With Pig Tail | 41A330375P1 |
| 25 | Clamp V Band GE 128 X | 1639 |
| 26 | Clean Out Cover Gasket | 126X1458 |
| 27 | Coalescer Air Filter | 41B511480P8 |
| 28 | Coalescer Element | 2X7463 |
| 29 | Compound, High Temperature - Sealant | 147X2395 |
| 30 | Connecting Rod, Articulating | 117X1012-4 |
| 31 | Connector | 41B561446G1 |
| 32 | Contactor Tip | 9960190G7 |
| 33 | Cut-out Cock | 140X2452 |
| 34 | Eb Ring Set, 7FDL | 150X1250 |
| 35 | Exhaust Valve- 45 Degrees | 123X1037-5 |
| 36 | Fan Clutch Carbon Brush | 998X90 |
| 37 | Flange Seal | 126X1461 |
| 38 | Friction Snubber, Horizontal | 41A244100AAP6 |
| 39 | Friction Snubber, Vertical | 41A244100AAP2 |
| 40 | Gasket At Bellows, 12/16 | 128X1637 |
| 41 | Gasket At Transition Section | 115X1914-2 |
| 42 | Gasket Kit, Cylinder Top Deck | 150X1087-1 |
| 43 | Gasket, 13"Od | 115X1931-1 |
| 44 | Gasket, 14.52" Long | 115X2494 |
| 45 | Gasket, Auxiliary Generator | 8805492P1 |
| 46 | Gasket, Bearing Cap | 8804066P1 |
| 47 | Gasket, Exhaust Stack | 115X2240-2 |
| 48 | Gasket, Gear Box To Frame | 8805493P1 |
| 49 | GE Inlet Valve | 123X1090C |
| 50 | Groove less Con Rod Bearing, Shell | 117X1050-1 |
| 51 | Idler Gear, Complete | 41C63523293G |
| 52 | Inlet Casing Assembly | 126X1492 |
| 53 | Inlet Flange | 126X1873 |
| 54 | Inlet Shroud | 126X1874 |
| 55 | Inlet Valve- 15 Degrees | 123X1090 |
| 56 | Kit, Cylinder Assembly | 150X1223-4 |
| 57 | Kit, Water Pump, Overhaul | 150X1069-3 |
| 58 | Large Turbine End Bearing | 126X1222-1 |
| 59 | Liner, Valve Guide, Spring | 121X1244-2 |
| 60 | Magnetic Pick-Up | 126X1389-1 |
| 61 | Master Connecting Rod | 117X1060 |
| 62 | Mystification Circuit Board | 1126691 |
| 63 | Nozzle Assembly, 10 X 0.400" X 150⁰ | 123X1098 |
| 64 | Nozzle Ring | 126X1491-1 |
| 65 | Nut, Hex Head, 3/8"-24 | 126X1452 |
| 66 | Oil Seal | 115X1877 |
| 67 | Oil Seal, Blower | 126X1467 |
| 68 | Oil Seal, Blower End, 1616 | 126X1563 |
| 69 | Oil Seal, Turbine End | 126X1466-2 |
| 70 | Oil Seal, Turbine End | 126X1702 |
| 71 | O-Ring | 115X1146 |
| 72 | O-Ring | 115X1929-3 |
| 73 | PCB GE Analog Board | 1164355 |
| 74 | Radiator | 41D704572P1 |
| 75 | Radiator Boot | 41A2122813G1 |
| 76 | Retainer, Nozzle Ring | 126X1454 |
| 77 | Seal - 2.11" Od, Cylinder Head | 121X2635 |
| 78 | Seal Shaft Collar Felt | 41A233819P2 |
| 79 | Seat, Spring | 41A330248P1 |
| 80 | Small Turbine End Bearing | 126X1479 |
| 81 | Spring | 41A238759P1 |
| 82 | Spring Seat with Pin For Ag Traction Motor | 41A233867G5 |
| 83 | Switch, Pressure | 41B510557P15 |
| 84 | Transition Section - Cast | 128X1648-1 |
| 85 | Turbine End Bearing | 126X1699 |
| 86 | Turbine End Bearing | 84D721239P1 |
| 87 | Turbine Inlet Assembly | 126X1649 |
| 88 | Turbine Inlet Shell | 126X1488-1 |
| 89 | Turbine Inlet Shroud | 126X1449-1 |
| 90 | Valve GE 7FDL - Ex | 123X1037-4 |
| 91 | Valve Inlet | 123X100 |
GE Traction Gears & Pinion
| Sr. No. | Part Description | OEM Part No. |
|---|---|---|
| 1 | Gear - 90 Tooth | 41C637598PI |
| 2 | Gear - 91 Tooth | 8837760, 41B530121PI |
| 3 | Gear - 92 Tooth | 41C632784P2, 8837724 |
| 4 | Gear - 93 Tooth | 41C636682P1, 8837756P1 |
| 5 | Gear - 94 Tooth | 41C637211P1, 8837727P1 |
| 6 | Gear - 65 Tooth | 41C635820P1 |
| 7 | Gear - 74 Tooth | 41C632494P1 |
| 8 | Gear - 77 Tooth | 41C632350 |
| 9 | Gear - 83 Tooth | 41C636806P1 |
| 10 | Gear - 87 Tooth | 41D735826P2 |
| 11 | Gear - 90 Tooth | 41C632381P2 |
| 12 | Pinion 21 Tooth | 41C637595PI |
| 13 | Pinion 20 Tooth | 84C614909PI |
| 14 | Pinion 19 Tooth | 41C632785P2 |
| 15 | Pinion 18 Tooth | 41C635677PI, 41C637903 |
| 16 | Pinion 17 Tooth | 41C637180PI |
| 17 | Pinion 18 Tooth | 41C635796PI |
| 18 | Pinion 18 Tooth | 41C637399PI |
| 19 | Pinion 26 Tooth | 41C632349 |
| 20 | Pinion 20 Tooth | 41C636447P6 |
| 21 | Pinion 16 Tooth | 41D735825PI |
| 22 | Pinion 17 Tooth | 41C632382PI |
GE Electrical Contacts
| Sr. No. | Part Description | OEM Part No. |
|---|---|---|
| 1 | GE 259A5663G1 | 259A5663G1 |
| 2 | GE 3X6659 Contacts | 3X6659 |
| 3 | GE 3X6660 | 3X6660 |
| 4 | GE 482A946G1 | 482A946G1 |
| 5 | GE 6712788P1 Contacts | 6712788P1 |
| 6 | GE 8807882G1 | 8807882G1 |
| 7 | GE 8867977P1 / 2 Contacts | 8867977P1 |
| 8 | GE 8867977P1 / 2 Contacts | 8867977P2 |
| 9 | GE 9960190G7 | 9960190G7 |
GE Exhaust Manifolds
| Sr. No. | Part Description | OEM Part No. |
|---|---|---|
| 1 | Bellow | 128X1638 |
| 2 | Bellows Main (128 X 1648) | 128X1689 |
| 3 | Clamp V Band GE | 128X1639 |
| 4 | Transition Section - Cast | 128X1648-1 |
GE Alt. Gears & Pinions
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Drive Gear 102 Tooth | 41C633061PI |
| 2 | Gear 43 Tooth | 41C632663PI |
| 3 | Gear 43 Tooth | 41C635625PI |
| 4 | Gear 43 Tooth | 41C635800PI |
EMD Gasket Kits
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Kit Valve Repair | 40029184 |
| 2 | Kit Gasket - Aftercooler Changeout | 9580722 |
| 3 | Kit Gasket - Camshaft Drive Housing | 9575125 |
| 4 | Kit Gasket - Turbocharger Changeout | 40069484 |
| 5 | Kit Gasket - Lub Oil Pressure Pump | 9580728 |
| 6 | Kit Gasket - Water Pump Application | 9580723 |
| 7 | Kit Gasket - Cylinder Head Cover | 40012903 |
| 8 | Kit Gasket - Fuel Oil Manifold | 9580697 |
| 9 | Kit Gasket - Lub Oil Scavenging Pump | 9575132 |
| 10 | Kit Gasket - Cylinder Head Cover And Frame | 40052428 |
| 11 | Kit Gasket - Overspeed Trip Housing | 40052429 |
| 12 | Kit Gasket - Power Pack Installation | 9582482 |
| 13 | Kit Gasket - Cylinder Head - Integrated Gasket | 8479836 |
| 14 | Kit Gasket - Lub Oil Separator | 40052430 |
| 15 | Kit Gasket - Lub Oil Strainer | 40052426 |
| 16 | Head Gasket Kit / Liner | 8427111 |
| 17 | Kit Gasket - Power Pack Installation | 9583686 |
| 18 | Liner Kit | 9525089 |
EMD Filters
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Element - Filter | 8340000 |
| 2 | Element - Filter | 8322064 |
| 3 | Element - Fuel Filter - Spin - On | 8423132 |
| 4 | Oil Filter | 8345482 |
| 5 | Air Intake Filter | 9093588 |
| 6 | Fuel Filter Element | 40106208 |
| 7 | Oil Filter Element | 40056007 |
| 8 | Turbocharger Filter | 40058636 |
| 9 | Electrical Cabinet Air Filter | 40132026 |
| 10 | Air Filter Bag | 40086945 |
| 11 | Shell Assembly - Filter | 8327347 |
| 12 | Oil Filter | 8345482 |
| 13 | Air Intake Filter | 9093588 |
| 14 | Fuel Filter Element | 40106208 |
| 15 | Oil Filter Element | 40056007 |
| 16 | Turbocharger Filter | 40058636 |
| 17 | Electrical Cabinet Air Filter | 40132026 |
| 18 | Air Filter Bag | 40086945 |
| 19 | Element - Filter | 8340000 |
| 20 | Element - Filter | 8322064 |
EMD Filter Kits
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Kit, Filter | 8488617 |
| 2 | P2A Complete Kit | 8271917 |
| 3 | Rubber Kit | 8271904 |
| 4 | Moving Kit | 8271905 |
| 5 | Rubber Kit | 8271906 |
| 6 | Moving Kit | 8271907 |
| 7 | Rubber Kit | 8271910 |
| 8 | Moving Kit | 8271911 |
| 9 | Rubber Kit | 8271908 |
| 10 | Moving Kit | 8271909 |
| 11 | Rubber Kit | 8271916 |
| 12 | Rubber Kit | 8271914 |
| 13 | Complete Kit | 8273760 |
| 14 | Moving Kit | 8271915 |
EMD O RINGS & SEALS
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Seal Water Manifold | 8433272 |
| 2 | Seal Liner To Water Inlet Tube | 8305815 |
| 3 | Seal Lower Liner | 9316850 |
| 4 | Seal Water Outlet Elbow To Cylinder Head | 9317972 |
| 5 | Seal O Ring - Air Box Drain | 8198078 |
| 6 | Seal O Ring - Piston Cooling Oil | 8082587 |
| 7 | Seal Cylinder Test Valve | 40017341 |
| 8 | Seal - Oil Drain To Crankcase | 9529807 |
| 9 | Seal O Ring | 8423736 |
| 10 | Seal O Ring | 8429310 |
| 11 | Seal O Ring - Aux. Generator Drive | 8308292 |
| 12 | Seal O Ring - Stubshaft | 8294874 |
| 13 | Seal O Ring | 40047150 |
| 14 | Seal Pressure Elbow To Lub Oil Manifold | 8082586 |
| 15 | Seal O Ring Filter Discharge | 8280352 |
| 16 | Seal O Ring Filter Supply | 8366436 |
| 17 | Seal Water Pump - Outer | 9526863 |
| 18 | Seal Crankcase To Oil Pan | 8187010 |
| 19 | Seal O Ring - Cut-Off Valve & Flange Mounting | 8342588 |
| 20 | Silicone Cord Pie Shape Cyl Head Cover | 9575318 |
| 21 | Seal O Ring - Upper Header To Tank - Viton | 40044420 |
| 22 | Seal O Ring | 40065194 |
| 23 | Seal O Ring | 40061836 |
| 24 | Sealing Ring 31/32 | 9089588 |
| 25 | Sealing Ring | 9089590 |
| 26 | Sealing Ring | 9089591 |
| 27 | Sealing Ring | 9089592 |
| 28 | Sealing Ring | 9089593 |
| 29 | Sealing Ring | 9089595 |
| 30 | Seal | 8028752 |
| 31 | O-Ring Seal Flange Water Outlet Elbow | 8282233 |
| 32 | Sealing Ring | 9089594 |
| 33 | Seal Ring | 8476402 |
| 34 | Sealing Ring | 9089589 |
| 35 | Seal- O Ring Strainer | 8085182 |
| 36 | Seal-O-Ring | 8343161 |
| 37 | Seal- O Ring | 8478924 |
| 38 | Seal- O Ring | 9315446 |
| 39 | Seal- O Ring | 9557674 |
| 40 | Seal- O Ring | 10660839 |
EMD Miscellaneous Parts
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Adjusting Screw | 8052327 |
| 2 | Air Filter | 11664253 |
| 3 | Air Filter Assy | 40043929 |
| 4 | Air Inlet Duct | 40062584 |
| 5 | Bearing Ball Carrier | 40015822 |
| 6 | Bearing Carrier Drive Shaft Gear | 9416636 |
| 7 | Bearing Commutator Side | 8864951P65 |
| 8 | Block ASM... Bearing - Drilled Cap | 9542904 |
| 9 | Block ASM... Bearing - Plain Cap | 9542905 |
| 10 | Bolt | 8159340 |
| 11 | Bolt | 8242193 |
| 12 | Bolt ½” – 13 | 7884 |
| 13 | Bolt ASM | 8127868 |
| 14 | Bracket ASM... Bearing - Left Bank ACC End | 9544055 |
| 15 | Bracket ASM... Bearing - Left Bank Cam Shaft End | 9543649 |
| 16 | Bracket ASM... Bearing - Right Bank ACC End | 9544051 |
| 17 | Bracket ASM... Bearing - Right Bank Cam Shaft End | 9543492 |
| 18 | Bracket Bearing | 8069712 |
| 19 | C Link | 9528663 |
| 20 | Cap Main Brg | 9541512 |
| 21 | Cap Main Brg | 9541511 |
| 22 | Cap Main Brg | 9541514 |
| 23 | Cap Main Brg | 9090608 |
| 24 | Cap Main Brg | 5141514 |
| 25 | Cap Main Brg Centre | 8476507 |
| 26 | Cap Main Brg Centre | 16140886 |
| 27 | Cap Main Brg Genene | 8476509 |
| 28 | Cap Main Brg Genene | 16140862 |
| 29 | Cap Main Brg Inter | 8476510 |
| 30 | Cap Main Brg Inter | 16140874 |
| 31 | Car Body ASSM With Part Drawing | 40074009 |
| 32 | Carrier Bearing Retainer | 40039257 |
| 33 | Carrier Bolt / Bolt Hex Head 5/16 | 40039256 |
| 34 | Carrier EMD 645 E | 8367800 |
| 35 | Chamber Gasket Cooper | 40055466 |
| 36 | Chart-Grommet Strip | 9565052 |
| 37 | Chart-Shim | 8452073 |
| 38 | Clutch Dowelling ASM | 40001043 |
| 39 | Clutch Drive Assembly | 40001044 |
| 40 | Collar | 8320743 |
| 41 | Collar Adjustment | 8034849 |
| 42 | Collar | 8028464 |
| 43 | Conduit | |
| 44 | Counterweight Lb Front | 9545408 |
| 45 | Counterweight Lb Rear | 40033553 |
| 46 | Counterweight Rb Front | 40052883 |
| 47 | Counterweight Rb Rear | 40033554 |
| 48 | Cylinder Test Valve Assembly | 40035242 |
| 49 | Elbow | 8360557 |
| 50 | Elbow | 9534873 |
| 51 | Elbow Ems 40 | 8436703 |
| 52 | Elbow Lube Oil Pressure | 8436704 |
| 53 | Elbow Water Outlet Rb | 8346547 |
| 54 | Elbow Water Out Lt Lb | 8346691 |
| 55 | Elbow Water Outlet | 8414444 |
| 56 | Fuel Oil Line | 8039842 |
| 57 | Fuel Oil Line ASM | 8160209 |
| 58 | Inj Cont Shaft ASM Lb | 8196855 |
| 59 | Inj Cont Shaft ASM Rb | 8196856 |
| 60 | Inner Race 645 | 8135970 |
| 61 | Insert, Lower Liner, Crankcase & Oil Pan Asy | 8168641 |
| 62 | Lever | 8215509 |
| 63 | Lever | 8194651 |
| 64 | Lever Reset | 8029623 |
| 65 | Lube Oil Manifold End | 8288093 |
| 66 | Manifold Adapter Turbo Filter | 8366249 |
| 67 | Manifold -Centre | 8288094 |
| 68 | Nut Head To Liner / Hex Nut 3/4-16 | 8060089 |
| 69 | Ost Cover ASM | 9573981 |
| 70 | Rocker Arm Shaft | 8028460 |
| 71 | Roller 645 | 9319503 |
| 72 | Shaft ASM Lb | 8320751 |
| 73 | Shaft ASM -Ost | 8320750 |
| 74 | Y Flange | 8289021 |
EMD Exhaust Manifolds
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Exhaust Chamber | 10624476 |
| 2 | Exhaust Chamber | 40121220 |
| 3 | Exhaust Chamber | 40121219 |
| 4 | Exhaust Chamber | 40121218 |
| 5 | Exhaust Chamber | 40121217 |
| 6 | Exhaust Chamber | 8348830 |
| 7 | Exhaust Chamber Assembly Front | 9316231 |
| 8 | Exhaust Chamber Assembly Intermediate Front | 9316232 |
| 9 | Exhaust Chamber Assembly Intermediate Rear | 9316233 |
| 10 | Exhaust Chamber Assembly Intermediate Rear | 40089231 |
| 11 | Exhaust Chamber Assembly Rear | 9316234 |
| 12 | Exhaust Duct Assembly | 9529830 (16080452) |
| 13 | Exhaust Manifold Assembly Complete | 40071914 |
EMD Expansion Joints
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Expansion Joint Assembly 10 | 8408987 |
| 2 | Expansion Joint Assembly 14 | 8408985 |
EMD Exhaust Bellow Connectors
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | Bellow Connector 16 Cyl. | 8281052 |
EMD Exhaust Couplings
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Coupling Assembly 1" | 8476174 |
| 2 | Coupling Assembly 1" | 8472849 |
| 3 | Coupling Assembly 2" | 8474757 |
| 4 | Coupling Assembly 2" | 8479676 |
| 5 | Coupling Assembly 2.5" | 8392458 |
| 6 | Coupling Assembly 2.5" | 8472617 |
| 7 | Coupling Assembly 2.5" | 8472616 |
| 8 | Coupling Assembly 2.5" | 8275374 |
| 9 | Coupling Assembly 2.5" | 8284779 |
| 10 | Coupling Assembly 3" | 8468179 |
| 11 | Coupling Assembly 4" | 8252895 |
| 12 | Coupling Assembly 4" | 8474741 |
| 13 | Coupling Assembly 4" | 8470341 |
| 14 | Coupling Assembly 4" | 8347788 |
| 15 | Coupling Assembly 5" | 9559099 |
| 16 | Coupling Flex 1" | 8470340 |
| 17 | Coupling Flex 2.5" | 9516671 |
| 18 | Coupling Flex 3" | 8471160 |
| 19 | Coupling Flex 3" | 8468179 |
| 20 | Coupling Flex 3/4" | 8479674 |
| 21 | Coupling Flex 3/4" | 8470605 |
| 22 | Coupling Flex 4" | 8252895 |
| 23 | Coupling Flex 1/2" | 8476711 |
EMD Other Parts
| Sr. No. | Part Description | EMD Part No. |
|---|---|---|
| 1 | 90 Degree Elbow | 8455470 |
| 2 | Adapter & Screen Assembly | 9557143 |
| 3 | Screen | 9526330 |
| 4 | Short Extensions Exhaust | 8281051 |
| 5 | Spacer Bolt Assly. | 40055467 |
| 6 | Elbow 90 Degree Assembly 3" | 8455470 |
EMD Contactors
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Contactor | 8459983 |
| 2 | Contactor ...Gen…Field Decay - GFD | 8400143 |
| 3 | Contactor ...Gen…Field Decay - HFD | 8400143 |
| 4 | Contactor ...Generator Field…GF…See P.L.5401 | 8332661 |
| 5 | Contactor ...ST 2000 AMPS. 32 V.D.C. | 9315518 |
| 6 | Contactor ...ST 2000 AMPS. 32 V.D.C. | 9315518 |
| 7 | Contactor ...ST 2000 AMPS. 32 V.D.C. | 9315518 |
| 8 | Contactor Starting Auxiliary…ST…Formerly 8445890 | 8445890 |
| 9 | Contactors. Power - Pl -6, S14, 25, 36, B | 8461331 |
| 10 | Contactors. Power - Pl, 12, 34, 56, Sp14, 25, 36 | 8461332 |
| 11 | EMD Contactor | 40124229 |
| 12 | EMD Contactor ST | 9325207 |
| 13 | EMD Contactor ST | 9315518 |
| 14 | EMD Contactor ST | 8415485 |
| 15 | EMD GFC Contactor | 8330937 |
| 16 | EMD GFC Contactor | 8332661 |
| 17 | GFC Contactor | 8330937 |
| 18 | GFC Contactor | 8330937 |
| 19 | GFD Contactor | 40010561 |
| 20 | ST Contactors | 9325207 |
EMD Connectors
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Amphenol Connector 16 Pin | 8453146 |
| 2 | ST Connector | 8482180 |
| 3 | ST Connector | 8482180 |
EMD Electrical Contacts
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | EMD 40009951 (Round Tip) Contacts | 40009951 |
| 2 | EMD 6-43-7: 150 AMPS - 2 POLE | |
| 3 | EMD 6-43-8: 150 AMPS - 3 POLE | |
| 4 | EMD 6-45-2: 325 AMPS - 3 POLE Contacts | |
| 5 | EMD 8102509 (Square Tip) Contacts | 8102509 |
| 6 | EMD 8102509 Contacts | 8102509 |
| 7 | EMD 8102510 - 833050 Contacts | 8102510 |
| 8 | EMD 8102510 - 833050 Contacts | 8330350 |
| 9 | EMD 8209964 - (AGW TIP) Contacts | 8209964 |
| 10 | EMD 8209971 - (AGW TIP) Contacts | 8209971 |
| 11 | EMD 8251206 - (AGCDO TIP) Contacts | 8251206 |
| 12 | EMD 8251207 - (AGCDO TIP) Contacts | 8251207 |
| 13 | EMD 8260102 Contacts | 8260102 |
| 14 | EMD 8261218 Contacts | 8261218 |
| 15 | EMD 8262194 (Flat Tip) Contacts | 8262194 |
| 16 | EMD 8339355 | 8339355 |
| 17 | EMD 8339361 | 8339361 |
| 18 | EMD 8407132 | 8407132 |
| 19 | EMD 8409388 - (AGCDO TIP) Contacts | 8409388 |
| 20 | EMD 8409389 - (AGCDO TIP) Contacts | 8409389 |
| 21 | EMD 8424739 | 8424739 |
| 22 | EMD 8436607 | 8436607 |
| 23 | EMD 8468981 | 8468981 |
| 24 | EMD 9536539 - (AGW TIP) Contacts | 9536539 |
| 25 | EMD 9536540 - (AGW TIP) Contacts | 9536540 |
| 26 | EMD 9564547 (Radius Tip) Contacts | 9564547 |
EMD Rectifiers
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Rectifier | 2803017 |
| 2 | Rectifier | 8413371 |
| 3 | Rectifier ... 8.6 AMPS. - 108 Volts D.C.-Cr60 | 8158951 |
| 4 | Rectifier Assembly ... Silicon - Includes Terminal Block | 8421017 |
| 5 | Rectifier Assy ... Exciter Bridge - SCR | 8451653 |
| 6 | Rectifier Assy …Batt…Charge. - 250a.-Cr-Bc See Pl. 6903 | 8416096 |
| 7 | Rectifier...Bridge. Cr-GR | 8385325 |
EMD Relays
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | EMD Relay GR | 40050359 |
| 2 | GP Relay 4 No+ 4 Nc | 9516672 |
| 3 | Relay GR | 8360045 |
| 4 | Relay...See P.L. 5440 | 8357415 |
| 5 | Relay...See P.L. 5440 | 8363168 |
EMD Switches
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Switch | 8441983 |
| 2 | Switch ...Magnetic.B12, 24-M2, 23, 34 -Repl. 8335901 | 8464114 |
| 3 | Switch ...Magnetic.B21, 31, 32, 42, 51, 65, M16, 34, 36. Replaces 8328962 | 8464113 |
| 4 | Switch ...Magnetic.B32, B42, B51, B65, M36 | 8464116 |
| 5 | Switch ...Magnetic-RVF, RVR-Without Motor Cut-Out | 8464117 |
| 6 | Switch ...Slide...Iso...SW | 8330131 |
| 7 | Switch Rotary Snap | 8213093 |
| 8 | Switch Slide | 8455355 |
| 9 | Switch Slide Button. Control & Fuel Pump, Engine Run, Gauge Lights | 8330135 |
| 10 | Switch... Slide Button A-B Norm. Open | 8330133 |
| 11 | Switch...Rotary-Headlight-4 Pos.-4 POLE-Except 9510341 | 8243533 |
| 12 | Switch...Snap | 40009667 |
| 13 | Switch...Toggle...Cab Light | 8004611 |
EMD Sensors
| Sr. No. | Part Description | Part No. |
|---|---|---|
| 1 | Sensor Assembly...Etp1 7 Etp2 | 40029233 |
| 2 | Sensor...Pu | 40038643 |
| 3 | Traction Motor Speed Sensor | 40142706 |
| 4 | Traction Motor Temperature Sensor | 40171676 |
